STEREO INTEGRATED AMPLIFIER A 302U WITH BLUETOOTH

FEATURES

INPUTS AVAILABLE: PHONO, LINE 1, LINE 2, USB, DIGITAL(COAXIAL & OPTICAL) BLUETOOTH AND AN MP3 INPUT ON FRONT PANEL FOR EASY CONNECTIVITY TO YOUR PHONE /TABLET OR ANY OTHER DIGITAL DEVICE.

HEADPHONE SOCKET AVAILABLE FOR PERSONAL LISTENING.

DIRECT SWITCH AVAILABLE TO BYPASS TONE CONTROLS.

OUTPUTS AVAILABLE FOR 2 PAIRS OF SPEAKERS. EITHER ONE PAIR , OR BOTH PAIRS OF SPEAKERS CAN BE PLAYED SIMULTANEOUSLY IF THEY ARE RATED AT 8 OHMS IMPEDANCE

LINE OUT SOCKETS AND RECORD OUT SOCKETS AVAILABLE.

SPECIFICATIONS

OUTPUT POWER	45 WATT RMS/CH @ 8 OHMS IMPEDANCE AND 75 WATT RMS/CH @ 4 OHMS IMPEDANCE
TOTAL HARMONIC DISTORTION	≤ 0.5%
INPUT IMPEDANCE	47K OHMS
INPUT SENSITIVITY	300 mV
SIGNAL TO NOISE RATIO	80 dB
TREBLE	+/- 10 dB
BASS	+/- 10 dB
FREQUENCY RESPONSE	20Hz-20KHz
DIMENSIONS	430mm (W) x 350mm (D) x 70mm (H)

Note : As part of our continuing programme to improve the design and quality of our products we shall be free to make changes in the design and specifications without any notice.
