SPECIFICATIONS
|
D 420T |
D 520T |
D 620T |
DRIVER CONFIGURATION |
1×4″ Polypropylene mid-bass and 1×0.5″ mylar tweeter |
1×5.25″ Polypropylene mid-bass and 1×0.5″ mylar tweeter |
1×6.5″ Polypropylene mid-bass and 1×0.5″ mylar tweeter |
IMPEDANCE |
8 Ohms |
8 Ohms |
8 Ohms |
SWITCH AVAILABLE ON REAR SIDE TO SELECT TAPPINGS ON 100V LINE |
2W, 4W, 8W, & 16W |
2W, 4W, 8W, & 16W |
4W, 8W, 16W, & 32W |
Frequency response |
100Hz – 20KHz |
80Hz – 20KHz |
50Hz – 20KHz |
Sensitivity |
88dB |
89dB |
90dB |
MAX POWER AT 8 OHMS |
60 Watt |
80 Watt |
100 Watt |
Dimensions |
126 mm(W) x 195 mm(H) x 127mm(D) |
163 mm(W) x 252 mm(H) x 165mm(D) |
196 mm(W) x 302 mm(H) x 193mm(D) |
Note: As part of our continuing programme to improve the design and quality of our products we shall be free to make changes in the design and specifications without any notice.
